Middle Glass Railing Post with Point Glass Adaptors 40×40 H-1130 mm

Middle Glass Railing Post with Point Glass Adaptors STA-1139 is designed for modern side-mounted glass railing systems. The post is manufactured from a strong 40×40×2 mm square profile and is installed on the side of a balcony, terrace, staircase or other load-bearing structure. This middle post is designed to support two adjacent glass panels using point glass adaptors on both sides of the post.

The total post height is 1130 mm. Because the post is side mounted and its lower section extends below the floor level, the finished railing height from the floor is 1000 mm. This model has no handrail support and is designed for glass railing systems without a handrail.

The post is manufactured from high-quality AISI 304 stainless steel with a satin brushed finish. The point glass adaptors are suitable for 8–18 mm thick glass. Side mounting allows more efficient use of balcony, terrace or staircase space because the post does not occupy space on the floor surface.

We manufacture the railing posts ourselves, allowing us to modify standard dimensions, point glass adaptor positions, mounting solutions and other structural details according to customer requirements. Custom railing posts can also be manufactured according to the specific requirements of your project.

Technical Information

• Product code: STA-1139
• Type: Middle side-mounted railing post with point glass adaptors
• Post height: 1130 mm
• Finished railing height from floor: 1000 mm
• Profile: 40×40×2 mm
• Handrail: Without handrail
• Material: AISI 304 stainless steel
• Finish: Satin brushed
• Installation: Side mounted
• Glass holders: Point glass adaptors on both sides of the post
• Glass thickness: 8–18 mm
• Weight: 3.45 kg

Features

• Middle post designed to support two adjacent glass panels.
• Glass is fixed using point glass adaptors on both sides of the post.
• Strong 40×40×2 mm square profile.
• Manufactured from AISI 304 stainless steel.
• Point glass adaptors suitable for 8–18 mm thick glass.
• Finished railing height from the floor is 1000 mm.
• Side-mounted design maximises usable balcony, terrace or staircase space.
• Designed for glass railing systems without a top handrail.
• Manufactured by us – post dimensions, glass adaptor positions and other structural details can be customised.

Applications

• Glass balcony railings
• Glass terrace railings
• Glass staircase railings
• Straight glass railing sections
• Side-mounted glass railing systems
• Glass railings without a handrail
• Residential and commercial buildings

Installation

The post is side mounted to a balcony, terrace, staircase or other suitable load-bearing structure. The total post height is 1130 mm, but its lower section extends below the floor level. Therefore, the finished railing height from the floor after installation is 1000 mm.

STA-1139 is used as a middle post in straight glass railing sections. Two adjacent glass panels are fixed using point glass adaptors positioned on both sides of the post. The adaptors are suitable for 8–18 mm thick glass.

More information about railing installation can be found on our Railing Installation Videos page.

Related Products

• Railing Posts
• Glass Railing Posts with Square Profile
• Glass Adaptors
• Railing Components

Frequently Asked Questions

How does STA-1139 differ from an end railing post?
STA-1139 is a middle post designed to support two adjacent glass panels. Point glass adaptors are positioned on both sides of the post.

What is the finished railing height after installation?
The total post height is 1130 mm, but because the post is side mounted, its lower section extends below the floor level. The finished railing height from the floor is 1000 mm.

Is this post designed for railings without a handrail?
Yes. STA-1139 does not have a top handrail support and is designed for glass railing systems without a handrail.

What glass thickness is suitable?
The point glass adaptors are suitable for 8–18 mm thick glass.

How is the railing post installed?
The post is side mounted to a balcony, terrace, staircase or other suitable load-bearing structure.

Can the post dimensions or design be customised?
Yes. We manufacture the railing posts ourselves, so the dimensions, point glass adaptor positions, mounting solutions and other structural details can be customised according to individual project requirements.
